| Swing | 16" | 406.4 mm |
| Machining Length | 30" | 762 mm |
| # Axis | 2 | 2 |
| Chuck Size | 8" | 203.2 mm |
| Bar Capacity | 2.12" | 53.848 mm |
| Power | 7.5 hp | 5.6 kW |
| Max RPM | 2,500 RPM | 2,500 RPM |
| Turning Dia | 16" | 406.4 mm |
| Tailstock | Yes | Yes |
| Live Tooling | No | No |
| Sub Spindle | No | No |
| Dimensions | 87" x 45" x 67" | 87" x 45" x 67" |
| Weight | 3420 lbs | 3420 lbs |
SPECIFICATIONS:
CHUCK SIZE:8"
SWING:16"
BAR CAPACITY:2.12"
POWER:7.5 HP
MAX RPM:2,500 RPM
TAILSTOCK: YES
HEIGHT OF CENTERS:8"
SWING OVER BED:16"
SWING OVER SADDLE WINGS:16"
SWING OVER CROSS SLIDE:8.6"
CROSS SLIDE TRAVEL:8.5"
COOLANT RESERVOIR CAPACITY: 9.3 GAL.
HEAD STOCK LUBRICATION: OIL BATH
# AXIS: 2
100 IPM ON X AXIS
150 IPM ON Z AXIS
WIDTH OF BED:12.6"
SPINDLE NOSE: D1-6
SPINDLE THROUGH HOLE:2.12"
SPINDLE DIA AT FRONT BEARING:3.15"
NUMBER OF SPEEDS OR RANGES:1
QUILL TRAVEL:6.3"
QUILL DIAMETER:2.36"
MACHINING LENGTH:30"
SIZE:16" X 30"
WEIGH2875 LBS
NET (L X W X H), LBS.: 82 X 46 X 72
HARDWARE
Tailstock
Tooling Kit (DORIAN TOOL POST+Holders, TOOLING NOT INCLUDED)
5C Collet Closer
Face Plate
Follow Rest
Steady Rest
Remote Stop/Go Safety Switch
SOFTWARE OPTIONS
TRAKing
DXF Converter
Advanced Features
Network
